Rear 500-1000wE-BikeKit Geared Motor - Wheel Only

• Rear geared hub motor wheel for efficient, responsive electric assist
• Hand-built in Pennsylvania, USA by experienced wheelbuilders
• 12-gauge stainless steel spokes with brass nipples
• Eyeletted double-wall rim for strength and long-term durability
• Supports 36V and 48V systems (500W–1000W performance range)

A premium rear motor wheel designed and tested as part of the E-BikeKit electric conversion system for reliable performance and durability.

Rear Geared Hub Motor Wheel (500W–1000W)

The E-BikeKit™ Rear Geared Hub Motor Wheel combines a powerful internally geared motor with a professionally hand-built wheel for smooth, efficient, everyday riding.

Every wheel is built by hand in Pennsylvania, USA using a double-wall, eyeletted rim, 12-gauge stainless steel spokes, and brass nipples. This construction ensures precise spoke tension, excellent strength, and long service life.

This rear motor wheel is engineered specifically for use with E-BikeKit controllers, wiring, and batteries. While similar components may appear compatible, proper operation and long-term reliability cannot be guaranteed when used with third-party systems.

Rear drivetrain note: A freewheel is not included when purchasing the motor as a wheel-only option and must be selected separately if needed.

Installation: Many customers install this wheel themselves using basic tools. A local bike shop can also complete installation quickly if preferred.

• Brand: E-BikeKit
• Motor Type: Internally geared, brushless (disc brake compatible)
• Nominal Power: 500W
• Peak Output: >750W @36V / >1000W @48V
• Maximum Torque: 75 Nm @36V / 84 Nm @48V
• Maximum RPM: 259 @36V / 320 @48V
• Cable: 8" axle exit, 3-phase with 5 hall sensors
• Connector: Round 8-pin, 13/32" (10.4 mm)
• Weight: 9.4 lbs (4.26 kg)
• Warranty: 1-year (up to 48V, 300 lb max load)
